Minisforum N5 Max Review: A Strix Halo NAS for Storage and Local AI

The N5 Max puts AMD’s Ryzen AI Max+ 395 — the chip in the best AI mini PCs — inside a five-bay NAS with five M.2 slots and two 10GbE ports. It can store your files and run language models on them without anything leaving your network. Since our launch preview in April, it has shipped, gained a 128GB version and been reviewed: the hardware is impressive, the software is not there yet.

In short

7.0 / 10

The N5 Max is the most powerful NAS you can buy for home or small office, and the only one that runs large AI models well: Strix Halo with 64GB or 128GB, ten drive slots and dual 10GbE. ITPro found Minisforum’s own NAS software immature and the default graphics memory limit too low for big models, but TrueNAS and OpenMediaVault run well on it. Buy it if you are comfortable setting up your own NAS software; otherwise wait, or pair a simpler NAS with an AI mini PC.

What changed in this update (Oct 12, 2026)

Our April article was a launch preview with specifications only and a provisional 9.2/10. Since then the N5 Max has shipped (June 2026, 64GB), a 128GB version has followed (August 2026), and ITPro has published a hands-on review. We replaced our estimated AI speeds with measured figures, corrected the memory (64GB at launch, 128GB now available, both soldered), and lowered the score to 7.0/10 to reflect the immature software. Printed prices are gone: Minisforum changed them several times.

Specifications

Ryzen AI Max+ 395 with Radeon 8060S, 64GB or 128GB of soldered LPDDR5X, five SATA bays and five M.2 slots, two 10GbE ports, USB4 v2, HDMI 2.1 and an internal 250W power supply.

Minisforum N5 Max specifications (Minisforum, Liliputing, Notebookcheck, ITPro; checked October 2026)
ComponentSpecification
ProcessorAMD Ryzen AI Max+ 395 (Zen 5) · 16 cores / 32 threads · 50 TOPS NPU
GraphicsRadeon 8060S · 40 RDNA 3.5 compute units
Memory64GB LPDDR5X (launch, June 2026) or 128GB (since August 2026) · soldered
Drive bays5× 3.5″ / 2.5″ SATA · RAID 0, 1, 5, 6, 10 and JBOD
M.2 slots5× M.2 2280 · one PCIe 4.0 x4, the others PCIe 4.0 x1 · a 128GB system SSD uses one slot
Network2× 10GbE · no Wi-Fi
USB and display2× USB4 v2 80Gbps · 1× USB4 40Gbps · 2× USB 3.2 Gen 2 Type-A · 1× USB 2.0 · HDMI 2.1
Power and coolingInternal 250W power supply · 5 heat pipes, 5 fans
SoftwareMinisCloud OS with the OpenClaw AI agent framework · also runs Windows, Linux, TrueNAS, OpenMediaVault and Unraid
Size199 × 202 × 252 mm · aluminum chassis
WarrantyTwo years, return to base (ITPro)

Drives are not included

The N5 Max ships with a small system SSD only. Budget for hard drives or SSDs on top of the price, and remember that up to 200TB is a theoretical maximum with five 30TB hard drives plus large SSDs.

Storage and network

Ten drive slots and two 10GbE ports make it a serious NAS; only one M.2 slot runs at full PCIe 4.0 x4 speed, which suits an SSD cache or a model library rather than an all-flash array.

Five SATA bays take 3.5-inch hard drives for bulk storage and five M.2 slots take SSDs for fast data or AI models. Four of the M.2 slots run at PCIe 4.0 x1, roughly 2 GB/s each, which is still faster than one 10GbE link. ITPro built a RAID 5 array from five hard drives plus a mirrored SSD pair; in its tests TrueNAS gave the best storage results, while Minisforum’s MinisCloud OS topped out around 590 MB/s in ATTO.

Local AI performance

Measured speeds match other Strix Halo machines once the graphics memory limit is raised: about 72 tokens per second on Llama 3.2 3B and on GPT-OSS 20B with Vulkan.

ITPro measurements on the 64GB N5 Max (August 2026)
ModelBackendTokens per second
Llama 3.2 3BGPUabout 72
GPT-OSS 20B (MXFP4)Vulkan72.9
GPT-OSS 20BROCm40+
GPT-OSS 20BNPU (Lemonade)18.9
Gemma 4 26B (mixture-of-experts)GPUabout 44
Gemma 4 31B (dense)GPUabout 9

The catch is the BIOS: by default it reserves only about 30GB for the GPU on the 64GB model (48GB at most), which made a 70B model hard to run in ITPro’s tests. The 128GB version removes that ceiling for 70B–120B models; on other Strix Halo machines with 128GB, GPT-OSS 120B runs at about 31 to 54 tokens per second and a dense 70B model at about 5. The pre-installed OpenClaw framework serves models to other devices on the network, which is the N5 Max’s real purpose: a private assistant that can search and summarize the documents stored on it.

Software: the weak point

ITPro called MinisCloud OS “terrible”: no web administration, no app store and no configuration backup at the time of its review. TrueNAS and OpenMediaVault work well instead.

A NAS lives or dies by its software, and Minisforum’s is young. ITPro also noted a fragile drive caddy lever. The good news is that the N5 Max is an open x86 machine: TrueNAS SCALE, OpenMediaVault, Unraid or a Linux server with Ollama all install on it, and ITPro’s best storage results came from TrueNAS. If you are not comfortable doing that, a Synology or QNAP NAS paired with a separate AI mini PC is the simpler route today.

Alternatives

Main alternatives to the N5 Max
OptionKey differenceChoose it if
Minisforum N5 ProRyzen AI 9 HX 370, upgradeable ECC DDR5, same 5-bay designStorage comes first and AI is occasional; much cheaper
Minisforum MS-S1 MaxSame chip, 128GB, dual 10GbE, no drive baysYou want an AI workstation and already have a NAS. Review
GMKtec EVO-X2Same chip in a compact mini PCYou want local AI on a desk, without storage features. Review

Who should buy it

Buy the N5 Max if you…
  • want storage and private AI in one always-on box
  • are comfortable installing TrueNAS or a Linux server
  • need dual 10GbE and many drive slots
  • will use 128GB for large models
Look elsewhere if you…
  • want a NAS that works well out of the box
  • only need storage: an N5 Pro or a Synology costs far less
  • only need AI: a Strix Halo mini PC costs less
  • need Wi-Fi

Pros and cons

Pros
  • Strix Halo: fast local AI with up to 128GB
  • 5 SATA bays and 5 M.2 slots
  • Dual 10GbE, USB4 v2
  • Internal power supply, strong cooling
  • Runs TrueNAS, OpenMediaVault, Unraid
Cons
  • Immature MinisCloud OS
  • Default BIOS limits GPU memory to about 30GB
  • Four of five M.2 slots at PCIe x1
  • No Wi-Fi, fragile drive caddy lever
  • Very high price, drives extra
Category scores (/10, our estimates)
CategoryScore
Hardware and expandability9.0
Local AI8.5
Network9.0
NAS software4.0
Value5.0

Verdict

7.0/10 — a remarkable machine for technical users who will run their own NAS software; for everyone else, a great idea that needs better software.

ITPro summed it up as “a great idea that’s come too soon”. The hardware delivers: Strix Halo’s AI performance, ten drive slots and dual 10GbE in one well-cooled box. If you install TrueNAS or a Linux server yourself and take the 128GB version for large models, it replaces both a NAS and an AI mini PC. If you expect a polished NAS experience, wait for Minisforum’s software to mature.

FAQ

What is the Minisforum N5 Max?

A five-bay NAS built around the AMD Ryzen AI Max+ 395 (Strix Halo), with five M.2 slots, two 10GbE ports, 64GB or 128GB of memory and MinisCloud OS with the OpenClaw AI framework. It stores files and runs local AI models in the same box.

Does the N5 Max have 64GB or 128GB of RAM?

Both exist. It launched in June 2026 with 64GB, and a 128GB version became available worldwide in August 2026. The memory is soldered, so choose 128GB if you plan to run 70B–120B models.

Can it run TrueNAS or Unraid?

Yes. ITPro tested TrueNAS and OpenMediaVault, and TrueNAS gave the best storage results. Unraid, Windows and Linux are also supported.

How fast is it for local AI?

ITPro measured about 72 tokens per second on Llama 3.2 3B and 72.9 on GPT-OSS 20B with Vulkan, and about 9 on a dense 31B model. Raise the BIOS graphics memory limit before loading large models.

N5 Max or N5 Pro?

The N5 Pro uses a Ryzen AI 9 HX 370 with upgradeable ECC DDR5 and costs much less; it is the better NAS for most people. The N5 Max is for running large AI models on the NAS itself.

Sources

  1. ITPro, Minisforum N5 Max review (Aug 2026)
  2. Liliputing, N5 Max launch and specifications (June 2026)
  3. Notebookcheck, 128GB configuration (Aug 2026)
  4. Tom’s Hardware, N5 Max announcement (Apr 2026)
  5. Strix Halo LLM speeds on 128GB machines (Sept 2026)
